About BC40 MEGA
The BC40 MEGA is a high-density immersion cooling design with the goal of providing a full-stack solution for large-scale mining customers. It integrates all required devices such as power distribution cabinets, smart PDUs, network interfaces, controllers, cooling tanks, circulation ducts, etc. Aims to provide miners with a turn-key mining installation.
Fog Hashing uses single-phase immersion cooling technology for cooling miners or servers. By immersing the miner in dielectric coolant, the heat generated by the ASIC chips is transferred to an external cooler or other dissipation equipment through specially-designed fluids. The precise control of the circulating fluids keeps the chipsets running at their optimum performance. Dust-free and static-free environment greatly reduces maintenance costs. Adaptive thermal design results in extremely low power consumption for heat dissipation (PUE<1.05).
Support customization
The BC40 MEGA supports customized external cooling options based on the deployment environment and requirements.
- geographic location
- Ambient temperature Humidity
- source of water
- overclocking range
- Run the type of mining machine
-
BC40 MEGA
Outer size
12192×2438×2896 mmAmount of machines
B24 tanks *16, to support 384 Antminers/480 WhatsminersInput voltage
3-phase 350-480V 50/60HzPower load (max)
1.9MW (After overclocking)Output voltage
200-277V, 50/60Hz
Network
1000Mbps Ethernet switch *2
Internal system Including
B24 tanks, B24R racks, Circulation system, Powerdistribution, Network
Others
More than 10-year lifetime for the container -
BC20 MEGA
Outer size
5820×2438×2896 mmAmount of machines
B24 tanks *8, to support 192 Antminers/240 WhatsminersInput voltage
-Power load (max)
0.96MW (After overclocking)Output voltage
-
Network
1000Mbps Ethernet switch *1
Internal system Including
- -
BC10 MEGA
Outer size
2991 x 2438 x 2591 mmAmount of machines
B24 tanks *4, to support 96 Antminers/120 WhatsminersInput voltage
-Power load (max)
480kW (After overclocking)Output voltage
-Network
1000Mbps Ethernet switch *1Internal system Including
-
